Vacuum freeze dryer · Small-scale production
FD-20 vacuum freeze dryer
The high-capacity all-in-one — steady production of liquid fruit, vegetables and food for small plants.
The high-capacity all-in-one — steady production of liquid fruit, vegetables and food for small plants.
Confirmed in the quotation, scheduled from the deposit
T/T: 40% deposit, 60% balance before delivery. Final terms confirmed before contract
1 year from dispatch against workmanship defects; wear parts excluded
Video-guided installation and commissioning
Every machine passes a pre-delivery acceptance test at our factory.
Figures from the FD-20 quotation; final values per technical agreement.
| Model | FD-20 |
|---|---|
| Freeze drying area | 20 m² |
| Water capture / batch | 300 kg |
| Power | 39 kw / 380V / 50Hz |
| Heating mode | Shelf radiation |
| Shelf temperature | Ambient to +95 °C |
| Structure | All-in-one |
| Overall dimensions | 4200×1700×1850 mm |
| Weight | 4500 kg |
| Power consumption | 25–39 kw/h |
| Control | PLC |
Sizing help: How to choose an industrial freeze dryer · Freeze dryer ROI and running cost
Tell us the material, wet load and daily target — an engineer will size it and quote.
Every freeze dryer, drying and IQF model with specifications, build standards and what we need for a quotation. 6 pages, 1 MB.
